Modular Cleanroom Panels
A Cleanroom Partition System is a modular wall and enclosure solution designed to create controlled environments with strict standards for air quality, cleanliness, and contamination control. These systems are widely used in industries such as pharmaceuticals, healthcare, biotechnology, electronics, and laboratories, where maintaining a dust-free and sterile environment is critical.
Royal Aircon provides high-quality, modular cleanroom partition systems that ensure durability, flexibility, and compliance with international cleanroom standards.
ROYAL AIRCON Clean room Modular Panel Doors is specifically designed for aesthetic look and achieving project timelines while maintaining modular flexibility. The system offers progressive and non progressive designs to suit your needs with PCGI/PPGI/SS304/SS316 Options. We have taken the utmost care in offering our clients a wide range of options in panel thickness. The modular false ceilings are suspension type with walk on or non-walk on design as per requirement.
Both our wall panels / ceiling are inert, non particle shedding, forming part of a clean room aseptic envelope to enable conformity with FDA validation procedures and International standards.
General Specifications
| Parameter | Specification |
|---|---|
| Panel Thickness | 50 mm, 60 mm, 80 mm & 100 mm |
| Panel Width | 1200 mm |
| Insulation | PUF / Rockwool / Paper Honeycomb |
| Sheet Thickness | 0.6 / 0.8 / 1.0 mm |
| Sheet Finish | PCGI / PPGI / SS |
| Panel Connection | Aluminium interconnecting profile |
| Glazing | Flush 5 mm toughened glass on both sides |
| Door | PCGI Single / Double steel lock-formed construction |
| Coving | 50° radius aluminium snap-fit |
Cleanroom Modular Doors
We at Royal Aircon Manufacture High Quality Cleanroom Doors, Made by using galvanised steel. These Doors can be tailor made to suit the varied requirement of the esteemed client. Available in different specification, cleanroom doors are widely acknowledged by the customer.
Key Features:
- Galvanized and Stainless Steel in MOC
- Powder Coated upto 80 Microns
- Flushed Construction
- High Density 40 Kg/m3 Pre Insulated.
- Framing in High Gauge Galvanized Steel Powder Coated.
Specifications:
- Single Leaf & Double Leaf Shutters
- Standard Width upto 2000 mm.
- Standard Height 2100 mm
- Frame Thickness Available are 75 & 100 mm
- Size & Specification are Customised as per Customer
| Single Door Sizes (mm) | Double Door Sizes (mm) |
|---|---|
| 750 × 2100 | 1200 × 2100 |
| 900 × 2100 | 1500 × 2100 |
| 1000 × 2100 | 1800 × 2100 |
| 1200 × 2100 | 2000 × 2100 |
Modular Partition Panels
Our Range of Wall Panels are as follows| Sr. No. | Thickness | Standard Panel Dimensions (mm) | Bonded With |
|---|---|---|---|
| 1 | 50 mm | 3000 × 1200 | PUF / Rockwool / Paper Honeycomb |
| 2 | 60 mm | 3000 × 1200 | PUF / Rockwool / Paper Honeycomb |
| 3 | 80 mm | 3000 × 1200 | PUF / Rockwool / Paper Honeycomb |
| 4 | 100 mm | 3000 × 1200 | PUF / Rockwool / Paper Honeycomb |
Advantages of Using Modular Wall Panels
- Easy for Fabrication and Erection at Site.
- Lower in Cost & Flexible for any Further Changes Required.
- Easy for Shifting Modular Cleanrooms instead if Structural Rooms.
- Smooth, Comfortable & Easy to Clean.
- Door Compatible with Panels Material
- Better in Aesthetic Look
